Traffic Analysis for Serial0/0

System:voip. in
Maintainer:
Interface:Serial0/0 (2)
IP:No hostname defined for IP address (143.233.169.10)
Max Speed: 128 kBbits/s (ppp)

The statistics were last updated Monday, 16 September 2002 at 14:35 ,
at which time 'voip.' had been up for 17 days, 17:38:38.
`Daily' Graph (5 Minute Average)
Max In: 0.0 b/s (0.0%) Average In: 0.0 b/s (0.0%) Current In: 0.0 b/s (0.0%)
Max Out: 16.0 b/s (0.0%) Average Out: 16.0 b/s (0.0%) Current Out: 16.0 b/s (0.0%)
`Weekly' Graph (30 Minute Average)
Max In: 0.0 b/s (0.0%) Average In: 0.0 b/s (0.0%) Current In: 0.0 b/s (0.0%)
Max Out: 16.0 b/s (0.0%) Average Out: 16.0 b/s (0.0%) Current Out: 16.0 b/s (0.0%)
`Monthly' Graph (2 Hour Average)
Max In: 400.0 b/s (0.3%) Average In: 80.0 b/s (0.1%) Current In: 0.0 b/s (0.0%)
Max Out: 125.8 kb/s (98.3%) Average Out: 13.0 kb/s (10.2%) Current Out: 16.0 b/s (0.0%)
`Yearly' Graph (1 Day Average)
Max In: 126.2 kb/s (98.6%) Average In: 280.0 b/s (0.2%) Current In: 0.0 b/s (0.0%)
Max Out: 127.7 kb/s (99.8%) Average Out: 2648.0 b/s (2.1%) Current Out: 16.0 b/s (0.0%)

GREEN ### Incoming Traffic in Bits per Second
BLUE ### Outgoing Traffic in Bits per Second
DARK GREEN### Maximal 5 Minute Incoming Traffic
MAGENTA### Maximal 5 Minute Outgoing Traffic
