Traffic Analysis for Ethernet4/0/2

System:clayton. in
Maintainer:
Interface:Ethernet4/0/2 (3)
IP:No hostname defined for IP address (143.233.173.1)
Max Speed: 10 MBits/s (ethernetCsmacd)

The statistics were last updated Monday, 1 July 2002 at 12:05 ,
at which time 'clayton.' had been up for 5 days, 22:18:49.
`Daily' Graph (5 Minute Average)
Max In: 53.8 kb/s (0.5%) Average In: 5184.0 b/s (0.1%) Current In: 12.4 kb/s (0.1%)
Max Out: 18.0 kb/s (0.2%) Average Out: 6312.0 b/s (0.1%) Current Out: 11.4 kb/s (0.1%)
`Weekly' Graph (30 Minute Average)
Max In: 558.5 kb/s (5.6%) Average In: 7104.0 b/s (0.1%) Current In: 16.4 kb/s (0.2%)
Max Out: 70.2 kb/s (0.7%) Average Out: 6552.0 b/s (0.1%) Current Out: 12.4 kb/s (0.1%)
`Monthly' Graph (2 Hour Average)
Max In: 2665.0 kb/s (26.6%) Average In: 9232.0 b/s (0.1%) Current In: 8304.0 b/s (0.1%)
Max Out: 450.0 kb/s (4.5%) Average Out: 7776.0 b/s (0.1%) Current Out: 7976.0 b/s (0.1%)
`Yearly' Graph (1 Day Average)
Max In: 6862.7 kb/s (68.6%) Average In: 9648.0 b/s (0.1%) Current In: 3248.0 b/s (0.0%)
Max Out: 992.7 kb/s (9.9%) Average Out: 3576.0 b/s (0.0%) Current Out: 5520.0 b/s (0.1%)

GREEN ### Incoming Traffic in Bits per Second
BLUE ### Outgoing Traffic in Bits per Second
DARK GREEN### Maximal 5 Minute Incoming Traffic
MAGENTA### Maximal 5 Minute Outgoing Traffic
